Single Axis or Daul Axis Hall Effect Grip Joystick
Operated by the cross direction or any direction.
Hall sensor for angular-tetecting.
Various output formats are available.
Description
HJ70 series
Grip Multi-axis Joystick
Product Features
Spring return, single-axis or dual-axis operation.
Operated by the cross direction or any direction.
Hall sensor for angular-tetecting.
Various output formats are available.
Application
This series of products are mainly used in cranes, loaders, forklifts, excavators, aerial work platforms, tractors, harvesters, etc.
GENERAL SPECIFICATION
Electrical Specifications
Hall type
Power supply voltage | 5 ± 0.5Vdc |
Power supply current (rated power supply current) | <11mA (single axis) 22mA (dual axis) |
Limit allowable overvoltage | 20Vdc |
Reverse limit allowable voltage | -10Vdc |
Linear error of output voltage | <± 0.2V |
Mechanical Specifications
Deflection angle | ± 20 °in X and Y derections |
Mode of operation | Spring return |
Starting force | 5N |
Maximum operating force | 11N |
Limiting force | > 300N |
Expected lifecycles (X and Y axis) | > 2 million times (potentiometer type) |
> 5 million times (Hall type) | |
Weight | 450g (no upper end) |
Environmental Specifications
Working temperature | -30C ~ + 70 ℃ |
Storage temperature | -40 ℃ ~ + 85 ℃ |
Protection grade | IP65 (above the installation panel) |
Product selection
series
HJ70
Operation
1A | Single-axis front-back operation |
2AP | Dual axis cross operation direction |
2AC | Any operation direction of two axies |
Output signal
Hall type (supply voltage 5VDC)
H51 | Single Hall， 0.5 ~ 2.5 ~ 4.5Vdc voltage output |
H52 | Single Hall， 0 ~ 2.5 ~ 5Vdc voltage output |
H53 | Single Hall， 1.25 ~ 2.5 ~ 3.75Vdc voltage output |
H54 | Single Hall， 1.0 ~ 2.5 ~ 4.0Vdc voltage output |
H55 | Single Hall， 1.15 ~ 2.5 ~ 3.85Vdc voltage output |
2H51 | redundant Hal，l 0.5 ~ 2.5 ~ 4.5Vdc voltage output |
2H52 | Redundant Hall， 0 ~ 2.5 ~ 5Vdc voltage output |
2H53 | Redundant Hall， 1.25 ~ 2.5 ~ 3.75Vdc voltage output |
2H54 | Redundant Hall， 1.0 ~ 2.5 ~ 4.0Vdc voltage output |
2H55 | Redundant Hall， 1.15 ~ 2.5 ~ 3.85Vdc voltage output |
2H56 | Redundant Hall， 1 ~ 2 ~ 4Vdc and 4 ~ 2 ~ 1Vdc voltage output |
Upper end of handle
KM | with safety switch, rocker switch |
KMNN | without safety switch and rocker button |
KMDN | with safety switch, without rocker button |
KMNR | no safety switch, rocker switch |
Outgoing way
A | horn connector (A2547HA-14P 2.54) |
XR9E Plug-in automotive connector (XR-9E connector) | |
L | direct outlet |
Dimensions
Product Installation
Electrical Installations
Hall type
Thread color function |
Gray Y-axis output |
Green background with white circle X axis output |
Blue Rocker switch common |
Purple safety switch |
Orange safety switch |
Black top switch left |
Red top switch right |
White Vin(+ 5Vdc,9~36V) |
Brown OV |
FAQ:
Q1: Are you joystick trade company or manufacturer?
A1: We are custom made industrial joystick controllers manufacturer with 20+ years experience.
Q2: How many pcs joystick do you produce every month?
A: We can produce more than 20000 pieces every month. Our company is growing, if you have greater demand, we can also increase production capacity in a short time.
Q3: How to achieve free maintenance for full life?
A3: If you are user, you can ship back to factory, after inspection and repair, send it back to the customer and provide a repair report.If you are dealer, we offer you free parts or ship back to repair. We can also provide exchange service.
Q4: Is there a user guide for the customized products?
A4: Yes, we offer the instruction of the customize joysticks. If need, we can offer video or online guidance. As usual, there is no instruction for the AWP joysticks used for after-sales maintenance, but if you have any questions, we can also answer for you.
Utility patent certificate
Quality certification
About shipping
Generally it will takes 2 weeks to finish product. If the customer needs joysticks urgently, we can follow the customer to deliver the goods in the fastest time.If it is a small batch order, we use express delivery to the door. If you order large quantities, you can choose sea, land or air freight.
Speed, Accuracy, Quality!
Service
We offer full life warranty for all of our joysticks.
